Micron Technology Inc. N25Q128A11ESE40F TR

Part No.:: N25Q128A11ESE40F TR

Manufacturer:: Micron Technology Inc.

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: N25Q128A11ESE40F TR.pdf

Description:: IC FLASH 128MBIT SPI 108MHZ 8SO

In Stock:: 2020

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

N25Q128A11ESE40F TR Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Obsolete
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
128Mb (32M x 4)
MemoryInterface:
SPI
ClockFrequency:
108 MHz
WriteCycleTime-WordPage:
8ms, 5ms
AccessTime:
-
Voltage-Supply:
1.7V ~ 2V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
