Macronix MX30LF4G18AC-TI

Part No.:: MX30LF4G18AC-TI

Manufacturer:: Macronix

Package:: 48-TFSOP (0.724, 18.40mm Width)

Datasheet:: MX30LF4G18AC-TI.pdf

Description:: IC FLASH 4GBIT PARALLEL 48TSOP

In Stock:: 3315

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MX30LF4G18AC-TI Specifications

Package/Case:
48-TFSOP (0.724, 18.40mm Width)
Packaging:
Tray
Series:
MX30LF
ProductStatus:
Not For New Designs
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NAND (SLC)
MemorySize:
4Gb (512M x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
20ns
AccessTime:
20 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
