Macronix MX29LV640EBTI-70G

Part No.:: MX29LV640EBTI-70G

Manufacturer:: Macronix

Package:: 48-TFSOP (0.724, 18.40mm Width)

Datasheet:: MX29LV640EBTI-70G.pdf

Description:: IC FLASH 64MBIT PARALLEL 48TSOP

In Stock:: 3729

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MX29LV640EBTI-70G Specifications

Package/Case:
48-TFSOP (0.724, 18.40mm Width)
Packaging:
Tray
Series:
MX29LV
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
64Mb (8M x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
70ns
AccessTime:
70 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
