Macronix MX25U51245GMI00

Part No.:: MX25U51245GMI00

Manufacturer:: Macronix

Package:: 16-SOIC (0.295, 7.50mm Width)

Datasheet:: MX25U51245GMI00.pdf

Description:: IC FLASH 512MBIT SPI/QUAD 16SOP

In Stock:: 2741

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MX25U51245GMI00 Specifications

Package/Case:
16-SOIC (0.295, 7.50mm Width)
Packaging:
Tube
Series:
MX25xxx45 - MXSMIO™
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
512Mb (64M x 8)
MemoryInterface:
SPI - Quad I/O, QPI, DTR
ClockFrequency:
166 MHz
WriteCycleTime-WordPage:
60µs, 750µs
AccessTime:
-
Voltage-Supply:
1.65V ~ 2V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
