Macronix MX25L25645GZNI-08G

Part No.:: MX25L25645GZNI-08G

Manufacturer:: Macronix

Package:: 8-WDFN Exposed Pad

Datasheet:: MX25L25645GZNI-08G.pdf

Description:: IC FLSH 256MBIT SPI 120MHZ 8WSON

In Stock:: 3227

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MX25L25645GZNI-08G Specifications

Package/Case:
8-WDFN Exposed Pad
Packaging:
Tray
Series:
MXSMIO™
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
256Mb (32M x 8)
MemoryInterface:
SPI
ClockFrequency:
120 MHz
WriteCycleTime-WordPage:
30µs, 750µs
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
