Texas Instruments MSP430G2101IPW14R

Part No.:: MSP430G2101IPW14R

Manufacturer:: Texas Instruments

Package:: 14-TSSOP (0.173", 4.40mm Width)

Datasheet:: MSP430G2101IPW14R.pdf

Description:: IC MCU 16BIT 1KB FLASH 14TSSOP

In Stock:: 2621

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MSP430G2101IPW14R Specifications

Package/Case:
14-TSSOP (0.173", 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MSP430G2xx
RoHS:
RoHS
Speed:
16MHz
RAM Size:
128 x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
-
Mounting Type:
Surface Mount
Number of I/O:
10
Core Processor:
MSP430
Data Converters:
-
Oscillator Type:
Internal
Program Memory Size:
1KB (1K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
