Texas Instruments MSP430FR5994IPMR

Part No.:: MSP430FR5994IPMR

Manufacturer:: Texas Instruments

Package:: 64-LQFP

Datasheet:: MSP430FR5994IPMR.pdf

Description:: IC MCU 16BIT 256KB FRAM 64LQFP

In Stock:: 2717

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MSP430FR5994IPMR Specifications

Package/Case:
64-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MSP430™ FRAM
RoHS:
RoHS
Speed:
16MHz
RAM Size:
8K x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
Connectivity:
I²C, IrDA, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
CPUXV2
Data Converters:
A/D 17x12b
Oscillator Type:
External, Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FRAM
Operating Temperature:
-40°C ~ 85°C (TA)
