Texas Instruments MSP430FR5969IRGZR

Part No.:: MSP430FR5969IRGZR

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: MSP430FR5969IRGZR.pdf

Description:: IC MCU 16BIT 64KB FRAM 48VQFN

In Stock:: 3120

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MSP430FR5969IRGZR Specifications

Package/Case:
48-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MSP430™ FRAM
RoHS:
RoHS
Speed:
16MHz
RAM Size:
2K x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
Connectivity:
I²C, IrDA, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
40
Core Processor:
CPUXV2
Data Converters:
A/D 16x12b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FRAM
Operating Temperature:
-40°C ~ 85°C (TA)
