Texas Instruments MSP430F5438AIPZR

Part No.:: MSP430F5438AIPZR

Manufacturer:: Texas Instruments

Package:: 100-LQFP

Datasheet:: MSP430F5438AIPZR.pdf

Description:: IC MCU 16BIT 256KB FLASH 100LQFP

In Stock:: 3440

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MSP430F5438AIPZR Specifications

Package/Case:
100-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MSP430F5xx
RoHS:
RoHS
Speed:
25MHz
RAM Size:
16K x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
Connectivity:
I²C, IrDA, LINbus, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
87
Core Processor:
CPUXV2
Data Converters:
A/D 16x12b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
