Texas Instruments MSP430F135IPMR

Part No.:: MSP430F135IPMR

Manufacturer:: Texas Instruments

Package:: 64-LQFP

Datasheet:: MSP430F135IPMR.pdf

Description:: IC MCU 16BIT 16KB FLASH 64LQFP

In Stock:: 583

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MSP430F135IPMR Specifications

Package/Case:
64-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MSP430x1xx
RoHS:
RoHS
Speed:
8MHz
RAM Size:
512 x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
POR, PWM, WDT
Connectivity:
SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
48
Core Processor:
MSP430
Data Converters:
A/D 8x12b
Oscillator Type:
Internal
Program Memory Size:
16KB (16K x 8 + 256B)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
