NXP USA Inc. MPC8308VMAGDA

Part No.:: MPC8308VMAGDA

Manufacturer:: NXP USA Inc.

Package:: 473-LFBGA

Datasheet:: MPC8308VMAGDA.pdf

Description:: IC MPU MPC83XX 400MHZ 473MAPBGA

In Stock:: 2034

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MPC8308VMAGDA Specifications

Package/Case:
473-LFBGA
Packaging:
Tray
Series:
MPC83xx
Product Status:
Last Time Buy
Core Processor:
PowerPC e300c3
Numberof Cores/BusWidth:
1 Core, 32-Bit
Speed:
400MHz
Co-Processors/DSP:
-
RAM Controllers:
DDR2
Graphics Acceleration:
No
Display & Interface Controllers:
-
Ethernet:
10/100/1000Mbps (3)
SATA:
-
USB:
USB 2.0 (1)
Voltage-I/O:
1.8V, 2.5V, 3.3V
Operating Temperature:
0°C ~ 105°C (TA)
Grade:
-
Qualification:
Security Features:
