Freescale Semiconductor MPC8306SCVMABDCA

Part No.:: MPC8306SCVMABDCA

Manufacturer:: Freescale Semiconductor

Package:: 369-LFBGA

Datasheet:: MPC8306SCVMABDCA.pdf

Description:: POWERQUICC POWER ARCH SOC, 133MH

In Stock:: 248

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MPC8306SCVMABDCA Specifications

Package/Case:
369-LFBGA
Packaging:
Bulk
Series:
MPC83xx
Product Status:
Active
Core Processor:
PowerPC e300c3
Numberof Cores/BusWidth:
1 Core, 32-Bit
Speed:
133MHz
Co-Processors/DSP:
Communications; QUICC Engine
RAM Controllers:
DDR2
Graphics Acceleration:
No
Display & Interface Controllers:
-
Ethernet:
10/100Mbps (3)
SATA:
-
USB:
USB 2.0 (1)
Voltage-I/O:
1.8V, 3.3V
Operating Temperature:
-40°C ~ 105°C (TA)
Grade:
-
Qualification:
Security Features:
