NXP USA Inc. MPC5566MZP132

Part No.:: MPC5566MZP132

Manufacturer:: NXP USA Inc.

Package:: 416-BBGA

Datasheet:: MPC5566MZP132.pdf

Description:: IC MCU 32BIT 3MB FLASH 416PBGA

In Stock:: 2993

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MPC5566MZP132 Specifications

Package/Case:
416-BBGA
Packaging:
Tray
Series:
MPC55xx Qorivva
RoHS:
RoHS
Speed:
132MHz
RAM Size:
128K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
256
Core Processor:
e200z6
Data Converters:
A/D 40x12b
Oscillator Type:
External
Program Memory Size:
3MB (3M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
