Lite-On Inc. MOC3052S-TA

Part No.:: MOC3052S-TA

Manufacturer:: Lite-On Inc.

Package:: 6-SMD, Gull Wing

Datasheet:

Description:: OPTOISOLATOR 5KV TRIAC 6SMD

In Stock:: 3439

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MOC3052S-TA Specifications

Packaging:
Tape & Reel (TR)
Series:
MOC305x
ProductStatus:
Active
OutputType:
Triac
ZeroCrossingCircuit:
No
NumberofChannels:
1
Voltage-Isolation:
5000Vrms
Voltage-OffState:
600 V
StaticdV/dt(Min):
1kV/µs
Current-LEDTrigger(Ift)(Max):
10mA
Current-OnState(It(RMS))(Max):
-
Current-Hold(Ih):
400µA (Typ)
TurnOnTime:
-
Voltage-Forward(Vf)(Typ):
1.2V
Current-DCForward(If)(Max):
50 mA
OperatingTemperature:
-40°C ~ 100°C
MountingType:
Surface Mount

MOC3052S-TA this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including MOC3052S-TA price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for MOC3052S-TA to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

MOC3052S-TA information

Views：

MOC3052S-TA Typical application Circuitry

MOC3052S-TA

MOC3052S-TA is an optoisolator triac driver device, which includes a phototriac that is intended for triggering a discrete power triac in the interface of digital logic to AC power loads. This component is widely utilized in applications that require controlling high-voltage AC power with low-voltage control signals, such as solid-state relays, AC motor controls, and lighting controls.

Application Scenarios: A common application for MOC3052S-TA is in solid-state relays where it is used to control high-voltage AC equipment, such as industrial heaters or large lighting installations, via low-voltage control signals.

Parameter Features: The MOC3052S-TA is characterized by its ability to provide electrical isolation between the low-voltage input side and the high-voltage output side, its minimal trigger current requirement, and its capability to drive a power triac directly. It's also designed to work with a wide range of AC voltages, typically up to 600V.

Specific Circuit Connection:

1. Input Side Connection: The low-voltage control signal is applied to the input LED within the MOC3052S-TA, connecting to pins 1 (Anode) and 2 (Cathode). It's crucial to incorporate a current-limiting resistor in series with the input to safeguard the LED.

2. Output Side Triac Driving: Connect pin 6 of the MOC3052S-TA to the gate of an external power triac. This setup enables the MOC3052S-TA to trigger the power triac, allowing it to control the flow of AC power to the connected load.

3. Load Connection: The external power triac's main terminals (MT1 and MT2) are connected across the AC load and the AC supply. This configuration facilitates the control of high-voltage AC power to the load, with the MOC3052S-TA acting as the triggering mechanism.

4. Optoisolation: Ensure there is proper isolation between the input and output sections to prevent high-voltage hazards and protect the low-voltage control circuitry.

Design Considerations:

- Input Control Signal: The control signal must be sufficient to activate the MOC3052S-TA's internal LED without exceeding its maximum current rating to ensure reliable triggering of the external triac.

- External Triac Selection: The external power triac should be selected based on the load's voltage and current requirements, ensuring it can handle the maximum expected load with a suitable safety margin.

- Thermal Management: Consider the thermal aspects of both the MOC3052S-TA and the external power triac, particularly in high-power applications, to prevent overheating and ensure long-term reliability.

- Snubber Circuit: If controlling inductive loads, a snubber circuit may be necessary across the external triac's main terminals to protect against voltage spikes and to enhance the triac's turn-off performance.
