Fairchild Semiconductor MOC3041VM

Part No.:: MOC3041VM

Manufacturer:: Fairchild Semiconductor

Package:: 6-DIP (0.300, 7.62mm)

Datasheet:: MOC3041VM.pdf

Description:: TRIAC OUTPUT OPTOCOUPLER WITH ZE

In Stock:: 2295

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MOC3041VM Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
OutputType:
Triac
ZeroCrossingCircuit:
Yes
NumberofChannels:
1
Voltage-Isolation:
4170Vrms
Voltage-OffState:
400 V
StaticdV/dt(Min):
1kV/µs
Current-LEDTrigger(Ift)(Max):
15mA
Current-OnState(It(RMS))(Max):
-
Current-Hold(Ih):
400µA (Typ)
TurnOnTime:
-
Voltage-Forward(Vf)(Typ):
1.25V
Current-DCForward(If)(Max):
60 mA
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Through Hole
