ON Semiconductor MOC3041FR2VM

Part No.:: MOC3041FR2VM

Manufacturer:: ON Semiconductor

Package:: 6-SMD, Gull Wing

Datasheet:

Description:: OPTOISOLATOR 7.5KV TRIAC 6SMD

In Stock:: 3386

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MOC3041FR2VM Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
OutputType:
Triac
ZeroCrossingCircuit:
Yes
NumberofChannels:
1
Voltage-Isolation:
7500Vpk
Voltage-OffState:
400 V
StaticdV/dt(Min):
-
Current-LEDTrigger(Ift)(Max):
15mA
Current-OnState(It(RMS))(Max):
-
Current-Hold(Ih):
400µA (Typ)
TurnOnTime:
-
Voltage-Forward(Vf)(Typ):
-
Current-DCForward(If)(Max):
60 mA
OperatingTemperature:
-
MountingType:
Surface Mount
