NXP USA Inc. MMPF0100F9AZES

Part No.:: MMPF0100F9AZES

Manufacturer:: NXP USA Inc.

Package:: 56-VFQFN Exposed Pad

Datasheet:: MMPF0100F9AZES.pdf

Description:: IC REG CONV I.MX6 12OUT 56QFN

In Stock:: 3776

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MMPF0100F9AZES Specifications

Packaging:
Tray
Series:
Automotive, AEC-Q100
ProductStatus:
Active
Applications:
Converter, i.MX6
Voltage-Input:
2.8V ~ 4.5V
NumberofOutputs:
12
Voltage-Output:
Multiple
OperatingTemperature:
-40°C ~ 105°C (TA)
MountingType:
Surface Mount, Wettable Flank
