NXP USA Inc. MKL03Z32CAF4R

Part No.:: MKL03Z32CAF4R

Manufacturer:: NXP USA Inc.

Package:: 20-UFBGA, WLCSP

Datasheet:: MKL03Z32CAF4R.pdf

Description:: IC MCU 32BIT 32KB FLASH 20WLCSP

In Stock:: 3145

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MKL03Z32CAF4R Specifications

Package/Case:
20-UFBGA, WLCSP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Kinetis KL03
RoHS:
RoHS
Speed:
48MHz
RAM Size:
2K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, LVD, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
18
Core Processor:
ARM® Cortex®-M0+
Data Converters:
A/D 7x12b
Oscillator Type:
Internal
Program Memory Size:
32KB (32K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
