NXP USA Inc. MIMXRT1172AVM8A

Part No.:: MIMXRT1172AVM8A

Manufacturer:: NXP USA Inc.

Package:: 289-LFBGA

Datasheet:: MIMXRT1172AVM8A.pdf

Description:: IC MCU 32BIT EXT MEM 289MAPBGA

In Stock:: 2785

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MIMXRT1172AVM8A Specifications

Package/Case:
289-LFBGA
Packaging:
Tray
Series:
RT1170
RoHS:
RoHS
Speed:
800MHz
RAM Size:
2M x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SAI, SPDIF, SPI, UART/USART, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
-
Core Processor:
ARM® Cortex®-M7
Data Converters:
A/D 2x12b; D/A 1x12b
Oscillator Type:
Internal
Program Memory Size:
-
Program Memory Type:
External Program Memory
Operating Temperature:
-40°C ~ 125°C (TJ)
