Name: MC9S12DJ256MFUE
Brand: NXP USA Inc.
SKU: MC9S12DJ256MFUE
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. MC9S12DJ256MFUE

Part No.:: MC9S12DJ256MFUE

Manufacturer:: NXP USA Inc.

Package:: 80-QFP

Datasheet:: MC9S12DJ256MFUE.pdf

Description:: IC MCU 16BIT 256KB FLASH 80QFP

In Stock:: 474

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9S12DJ256MFUE Specifications

Package/Case:
80-QFP
Packaging:
Tray
Series:
HCS12
RoHS:
RoHS
Speed:
25MHz
RAM Size:
12K x 8
Core Size:
16-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
PWM, WDT
Connectivity:
CANbus, I²C, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
59
Core Processor:
HCS12
Data Converters:
A/D 16x10b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
