NXP USA Inc. MC9S12A256CPVE

Part No.:: MC9S12A256CPVE

Manufacturer:: NXP USA Inc.

Package:: 112-LQFP

Datasheet:: MC9S12A256CPVE.pdf

Description:: IC MCU 16BIT 256KB FLASH 112LQFP

In Stock:: 3176

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9S12A256CPVE Specifications

Package/Case:
112-LQFP
Packaging:
Tray
Series:
HCS12
RoHS:
RoHS
Speed:
25MHz
RAM Size:
12K x 8
Core Size:
16-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
PWM, WDT
Connectivity:
I²C, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
91
Core Processor:
HCS12
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
