NXP USA Inc. MC9S08PA4VTG

Part No.:: MC9S08PA4VTG

Manufacturer:: NXP USA Inc.

Package:: 16-TSSOP (0.173", 4.40mm Width)

Datasheet:: MC9S08PA4VTG.pdf

Description:: IC MCU 8BIT 4KB FLASH 16TSSOP

In Stock:: 2289

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9S08PA4VTG Specifications

Package/Case:
16-TSSOP (0.173", 4.40mm Width)
Packaging:
Tube
Series:
S08
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
128 x 8
Part Status:
Not For New Designs
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
14
Core Processor:
S08
Data Converters:
A/D 8x12b
Oscillator Type:
Internal
Program Memory Size:
4KB (4K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)

MC9S08PA4VTG this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including MC9S08PA4VTG price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for MC9S08PA4VTG to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

MC9S08PA4VTG information

Views：

MC9S08PA4VTG Typical application Circuitry

The MC9S08PA4VTG is an advanced, 8-bit microcontroller unit (MCU) that is part of NXP's S08 series. It integrates many functions into a small package, making it a powerful choice for various applications.

Key attributes of the MC9S08PA4VTG include:

- Processor: It features a HCS08 central processing unit (CPU).

- Memory: The chip has 4KB flash read/program/erase over the full operating voltage and temperature, and 256B RAM.

- I/O: It provides up to 26 general-purpose input/output (GPIO) pins.

- Clocking: It has a frequency-locked-loop (FLL) regulated by an internal or external reference in its internal clock source (ICS) module.

- Power Management: The MC9S08PA4VTG supports a wide range of operating voltage from 1.8V to 3.6V, and it also has ultra-low power modes for energy efficiency.

- Analog: There's an analog comparator on the chip and a 10-bit, 10-channel analog-to-digital converter (ADC).

- Timers: The MCU incorporates two 2-channel timer/PWM modules.

The MC9S08PA4VTG can be deployed in various applications including home appliances, industrial control systems, battery operated devices, and a lot more.

Let's consider an example application where the MC9S08PA4VTG is used to control a DC motor speed:

1. Powering Up the MCU: VDD (Pin 1) is connected to a 3.3V power supply and VSS (Pin 2) is connected to ground to provide power to the MCU.

2. Clock Source: EXTAL (Pin 4) and XTAL (Pin 5) pins can be used to connect an external crystal oscillator. This is optional as the MCU already has an internal clock source.

3. Motor Control: A GPIO pin such as PTB0 (Pin 11) can be used as a PWM output pin to control the DC motor speed. The DC motor's applied voltage is managed by a MOSFET whose gate this pin is attached to.

4. Motor Speed Feedback: The back EMF of the DC motor can be connected to an ADC channel, say ADP0 (Pin 17). This helps in obtaining feedback about the motor speed.

5. Communication: For debugging or other communications, UART pins PTC2/PTC3 (Pin 27/Pin 28) can be used.

While designing with the MC9S08PA4VTG, some important considerations include:

- Proper Decoupling: A decoupling capacitor should be placed as close as possible to the VDD and VSS pins to manage power supply noise.

- ESD Protection: Protection mechanisms should be used to prevent damage from electrostatic discharge during handling and operation.

- Thermal Management: Be sure to keep the chip within the recommended temperature range to prevent thermal issues that could cause functional problems or reduce the device's lifespan.

Always refer to the datasheet for a full description of the MC9S08PA4VTG and its operational requirements.
