NXP USA Inc. MC9S08DZ60AMLF

Part No.:: MC9S08DZ60AMLF

Manufacturer:: NXP USA Inc.

Package:: 48-LQFP

Datasheet:: MC9S08DZ60AMLF.pdf

Description:: IC MCU 8BIT 60KB FLASH 48LQFP

In Stock:: 3581

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9S08DZ60AMLF Specifications

Package/Case:
48-LQFP
Packaging:
Tray
Series:
S08
RoHS:
RoHS
Speed:
40MHz
RAM Size:
4K x 8
Core Size:
8-Bit
EEPROM Size:
2K x 8
Part Status:
Active
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
CANbus, I²C, LINbus, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
39
Core Processor:
S08
Data Converters:
A/D 16x12b
Oscillator Type:
External
Program Memory Size:
60KB (60K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)

MC9S08DZ60AMLF this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including MC9S08DZ60AMLF price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for MC9S08DZ60AMLF to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
