NXP USA Inc. MC9S08AW60CFUER

Part No.:: MC9S08AW60CFUER

Manufacturer:: NXP USA Inc.

Package:: 64-QFP

Datasheet:: MC9S08AW60CFUER.pdf

Description:: IC MCU 8BIT 60KB FLASH 64QFP

In Stock:: 2295

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9S08AW60CFUER Specifications

Package/Case:
64-QFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
S08
RoHS:
RoHS
Speed:
40MHz
RAM Size:
2K x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
I²C, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
S08
Data Converters:
A/D 16x10b
Oscillator Type:
Internal
Program Memory Size:
60KB (60K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
