Name: MC9S08AC16CFGE
Brand: NXP USA Inc.
SKU: MC9S08AC16CFGE
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. MC9S08AC16CFGE

Part No.:: MC9S08AC16CFGE

Manufacturer:: NXP USA Inc.

Package:: 44-LQFP

Datasheet:: MC9S08AC16CFGE.pdf

Description:: IC MCU 8BIT 16KB FLASH 44LQFP

In Stock:: 1336

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9S08AC16CFGE Specifications

Package/Case:
44-LQFP
Packaging:
Tray
Series:
S08
RoHS:
RoHS
Speed:
40MHz
RAM Size:
1K x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
I²C, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
34
Core Processor:
S08
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
16KB (16K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
