Name: MC9RS08KA8CTG
Brand: NXP USA Inc.
SKU: MC9RS08KA8CTG
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. MC9RS08KA8CTG

Part No.:: MC9RS08KA8CTG

Manufacturer:: NXP USA Inc.

Package:: 16-TSSOP (0.173", 4.40mm Width)

Datasheet:: MC9RS08KA8CTG.pdf

Description:: IC MCU 8BIT 8KB FLASH 16TSSOP

In Stock:: 613

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC9RS08KA8CTG Specifications

Package/Case:
16-TSSOP (0.173", 4.40mm Width)
Packaging:
Tube
Series:
RS08
RoHS:
RoHS
Speed:
20MHz
RAM Size:
254 x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
LVD, POR, PWM, WDT
Connectivity:
I²C
Mounting Type:
Surface Mount
Number of I/O:
14
Core Processor:
RS08
Data Converters:
A/D 12x10b
Oscillator Type:
Internal
Program Memory Size:
8KB (8K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
