Name: MC68HC16Z1CEH16
Brand: NXP USA Inc.
SKU: MC68HC16Z1CEH16
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

NXP USA Inc. MC68HC16Z1CEH16

Part No.:: MC68HC16Z1CEH16

Manufacturer:: NXP USA Inc.

Package:: 132-BQFP Bumpered

Datasheet:: MC68HC16Z1CEH16.pdf

Description:: IC MCU 16BIT ROMLESS 132PQFP

In Stock:: 3247

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC68HC16Z1CEH16 Specifications

Package/Case:
132-BQFP Bumpered
Packaging:
Tray
Series:
HC16
RoHS:
RoHS
Speed:
16MHz
RAM Size:
1K x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
POR, PWM, WDT
Connectivity:
EBI/EMI, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
16
Core Processor:
CPU16
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
-
Program Memory Type:
ROMless
Operating Temperature:
-40°C ~ 85°C (TA)

MC68HC16Z1CEH16 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including MC68HC16Z1CEH16 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for MC68HC16Z1CEH16 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.
