NXP USA Inc. MC68332GCEH16

Part No.:: MC68332GCEH16

Manufacturer:: NXP USA Inc.

Package:: 132-BQFP Bumpered

Datasheet:: MC68332GCEH16.pdf

Description:: IC MCU 32BIT ROMLESS 132PQFP

In Stock:: 743

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC68332GCEH16 Specifications

Package/Case:
132-BQFP Bumpered
Packaging:
Tray
Series:
M683xx
RoHS:
RoHS
Speed:
16MHz
RAM Size:
2K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
POR, PWM, WDT
Connectivity:
EBI/EMI, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
15
Core Processor:
CPU32
Data Converters:
-
Oscillator Type:
Internal
Program Memory Size:
-
Program Memory Type:
ROMless
Operating Temperature:
-40°C ~ 85°C (TA)
