NXP USA Inc. MC56F8366VFVE

Part No.:: MC56F8366VFVE

Manufacturer:: NXP USA Inc.

Package:: 144-LQFP

Datasheet:: MC56F8366VFVE.pdf

Description:: IC MCU 16BIT 512KB FLASH 144LQFP

In Stock:: 3113

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC56F8366VFVE Specifications

Package/Case:
144-LQFP
Packaging:
Tray
Series:
56F8xxx
RoHS:
RoHS
Speed:
60MHz
RAM Size:
18K x 16
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
POR, PWM, Temp Sensor, WDT
Connectivity:
CANbus, EBI/EMI, SCI, SPI
Mounting Type:
Surface Mount
Number of I/O:
62
Core Processor:
56800E
Data Converters:
A/D 16x12b
Oscillator Type:
External
Program Memory Size:
512KB (256K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
