ON Semiconductor MC14584BDR2G

Part No.:: MC14584BDR2G

Manufacturer:: ON Semiconductor

Package:: 14-SOIC

Datasheet:: MC14584BDR2G.pdf

Description:: IC INV SCHMITT 6CH 1-IN 14SOIC

In Stock:: 3951

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC14584BDR2G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
4000B
ProductStatus:
Active
LogicType:
Inverter
NumberofCircuits:
6
NumberofInputs:
1
Features:
Schmitt Trigger
Voltage-Supply:
3V ~ 18V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8.8mA, 8.8mA
LogicLevel-Low:
1.6V ~ 4.6V
LogicLevel-High:
3.4V ~ 10.5V
MaxPropagationDelay@VMaxCL:
80ns @ 15V, 50pF
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount

MC14584BDR2G this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including MC14584BDR2G price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for MC14584BDR2G to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

MC14584BDR2G information

Views：

MC14584BDR2G Typical application Circuitry

MC14584BDR2G

The MC14584BDR2G is a component belonging to the MC14500 series, specifically designed as a CMOS hex Schmitt-trigger inverter. This device is often used in digital circuits for its noise immunity and wave shaping capabilities.

1. Supply Voltage (VDD and VSS): To function, the MC14584BDR2G needs a power source. Within the designated voltage range of the chip, connect the VDD pin to a positive voltage source. The ground is linked to the VSS pin. This setup provides the necessary power for the chip's internal circuitry.

2. Inverter Inputs: The MC14584BDR2G features six independent inverters. Each inverter has an input pin. These pins are where the digital signals to be inverted are applied. The Schmitt-trigger configuration of these inputs ensures enhanced noise immunity, beneficial in digital applications where signal integrity is paramount.

3. Inverter Outputs: Corresponding to each input, the MC14584BDR2G has six output pins. The output of each inverter provides the logical inverse of its respective input. These outputs can be connected to other digital components, such as microcontrollers, LEDs, or further signal processing circuits, depending on the application requirements.

4. Stabilization with a Bypass Capacitor: To ensure stable operation, it's advisable to connect a bypass capacitor (typically 0.1 µF) close to the MC14584BDR2G's power supply pins. This capacitor acts to filter out any transient noise present in the power supply, thus safeguarding the chip against unintended fluctuations that might affect its performance.

In addition to these connections, it's important to consider the chip's environmental and electrical limits as stated in its datasheet, like the maximum operating temperature and voltage limits. Also, take into account the propagation delay inherent to the MC14584BDR2G, as this might be a critical factor in time-sensitive digital circuits. Proper PCB layout practices are also essential, particularly in minimizing noise and ensuring signal integrity, which is especially crucial when dealing with high-speed digital signals or in environments with significant electrical noise.
