Name: MC-10287BF1-HN4-M1-A
Brand: Renesas Electronics America Inc
SKU: MC-10287BF1-HN4-M1-A
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Renesas Electronics America Inc MC-10287BF1-HN4-M1-A

Part No.:: MC-10287BF1-HN4-M1-A

Manufacturer:: Renesas Electronics America Inc

Package:: 324-BGA

Datasheet:: MC-10287BF1-HN4-M1-A.pdf

Description:: IC MCU 32BIT 768KB ROMLSS 324BGA

In Stock:: 2620

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

MC-10287BF1-HN4-M1-A Specifications

Package/Case:
324-BGA
Packaging:
Tray
Series:
R-IN32M3
RoHS:
RoHS
Speed:
100MHz
RAM Size:
512K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
DMA, WDT
Connectivity:
CANbus, Ethernet, I²C, SCI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
96
Core Processor:
ARM® Cortex®-M3
Data Converters:
-
Oscillator Type:
Internal
Program Memory Size:
768KB (768K x 8)
Program Memory Type:
ROMless
Operating Temperature:
-40°C ~ 85°C (TA)
