Micron Technology Inc. M28W160CB70N6E

Part No.:: M28W160CB70N6E

Manufacturer:: Micron Technology Inc.

Package:: 48-TFSOP (0.724, 18.40mm Width)

Datasheet:: M28W160CB70N6E.pdf

Description:: IC FLASH 16MBIT PARALLEL 48TSOP

In Stock:: 3265

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

M28W160CB70N6E Specifications

Package/Case:
48-TFSOP (0.724, 18.40mm Width)
Packaging:
Tray
Series:
-
ProductStatus:
Obsolete
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH - NOR
MemorySize:
16Mb (1M x 16)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
70ns
AccessTime:
70 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

M28W160CB70N6E this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including M28W160CB70N6E price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for M28W160CB70N6E to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

M28W160CB70N6E information

Views：

M28W160CB70N6E Typical application Circuitry

M28W160CB70N6E

The M28W160CB70N6E is a flash memory chip developed by STMicroelectronics. As part of the flash memory family, this chip serves as a non-volatile storage solution that retains data even when power is turned off.

Application Scenarios: The M28W160CB70N6E is suitable for various applications, from embedded systems to data storage applications in devices that require a reliable memory solution with quick access times.

Main Parameters: Key features and specifications of the M28W160CB70N6E are:

- Non-volatile Flash memory technology.

- 16 Mbit (1M x16) storage capacity.

- Parallel interface.

- Fast read access time.

- Erase/Programmable capabilities.

- Boot block architecture, which allows the system to boot from the top or bottom of the memory map.

Circuit Connection:

Let's delve into using the M28W160CB70N6E in an embedded system application as the primary memory storage:

1. Power and Ground Pins: Connect VCC (pin 48) to the 3.3V power supply and VSS (pin 24) to the system's ground. The memory chip requires a stable power supply to operate efficiently.

2. Data Bus: Pins DQ0 to DQ15 (pin numbers 1 to 15 and 33 to 40) serve as the data bus. Connect these pins directly to the data bus of your microcontroller or microprocessor to facilitate data transfer.

3. Address Bus: Pins A0 to A19 (pin numbers 16 to 23 and 41 to 47) are used for addressing. Hook them up to the address bus of your microcontroller to select memory locations.

4. Control Pins: The M28W160CB70N6E uses several control pins:

- OE (pin 29) - Output Enable: Active low signal to enable the outputs.

- WE (pin 31) - Write Enable: Active low signal for writing operations.

- CE (pin 30) - Chip Enable: Active low signal to enable the chip.

Connect these control pins to the corresponding control outputs of your microcontroller.

5. Reset Pin:The RESET# (pin 32) is an active low pin that initializes the memory chip. It can be connected to a reset controller or directly to a microcontroller pin.

Design Considerations:

When integrating the M28W160CB70N6E into a design, some factors need attention:

1. Stable Power Supply: For reliable memory operations, ensure a clean and stable power source.

2. Decoupling Capacitors: Attach capacitors close to the VCC and VSS pins to filter noise and offer power stability during transient conditions.

3. Protection: Implement protection mechanisms like overvoltage and electrostatic discharge (ESD) protection.

4. Timing Considerations: Ensure correct timing sequences for read, write, and erase operations to avoid data corruption.

In sum, the M28W160CB70N6E provides a robust and efficient flash memory solution for numerous applications. By paying attention to the chip's connections, power needs, and timing requirements, designers can harness its full potential for reliable data storage.
