Analog Devices Inc. LT1761ES5-3.3#TRPBF

Part No.:: LT1761ES5-3.3#TRPBF

Manufacturer:: Analog Devices Inc.

Package:: SOT-23-5 Thin, TSOT-23-5

Datasheet:: LT1761ES5-3.3#TRPBF.pdf

Description:: IC REG LIN 3.3V 100MA TSOT23-5

In Stock:: 648

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LT1761ES5-3.3#TRPBF Specifications

Package/Case:
SOT-23-5 Thin, TSOT-23-5
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
OutputConfiguration:
Positive
OutputType:
Fixed
NumberofRegulators:
1
Voltage-Input(Max):
20V
Voltage-Output(Min/Fixed):
3.3V
Voltage-Output(Max):
-
VoltageDropout(Max):
0.45V @ 100mA
Current-Output:
100mA
Current-Quiescent(Iq):
-
Current-Supply(Max):
-
PSRR:
65dB (120Hz)
ControlFeatures:
Enable
ProtectionFeatures:
Over Current, Over Temperature, Reverse Polarity
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

LT1761ES5-3.3#TRPBF this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LT1761ES5-3.3#TRPBF price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LT1761ES5-3.3#TRPBF to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LT1761ES5-3.3#TRPBF information

Views：

LT1761ES5-3.3#TRPBF Typical application Circuitry

LT1761ES5-3.3#TRPBF

The LT1761ES5-3.3#TRPBF is a model from Linear Technology's LT1761 series, which are low-noise, low-dropout linear regulators (LDOs). This series is recognized for its ability to provide stable, regulated output voltages with low dropout and minimal noise, making it highly suitable for sensitive RF and analog circuitry. The LT1761ES5-3.3#TRPBF, with its fixed 3.3V output, is particularly useful in applications where a precise 3.3V power supply is required.

1. VIN (Input Voltage Pin): The source voltage is supplied to this pin. For the LT1761ES5-3.3#TRPBF, the input voltage should typically be slightly higher than 3.3V to ensure proper regulation, considering its low dropout characteristic.

2. GND (Ground Pin): This pin serves as the circuit's common ground. It is vital for establishing a reference point for the regulated output voltage.

3. VOUT (Output Voltage Pin): The regulated 3.3V output is provided at this pin. The LT1761ES5-3.3#TRPBF maintains a stable voltage level here, suitable for powering sensitive electronic components.

4. SHDN (Shutdown Pin): This pin is used to enable or disable the regulator. Applying a low voltage to SHDN turns off the LT1761ES5-3.3#TRPBF, effectively cutting off the output and reducing power consumption when the regulator is not needed.

5. BYP (Bypass Pin): For noise reduction, a small capacitor can be connected between this pin and ground. This helps in filtering high-frequency noise, making the LT1761ES5-3.3#TRPBF ideal for RF applications.

6. Circuit Design Tips:

- Ensure the input voltage is appropriate for the LT1761ES5-3.3#TRPBF, typically a bit higher than 3.3V.

- Careful layout planning is crucial, especially in noise-sensitive applications, to maintain the regulator's low-noise performance.

- Selection of bypass capacitors should be based on the desired noise reduction level.

- Incorporating safety features, such as overcurrent protection, is recommended for circuit reliability.

The LT1761ES5-3.3#TRPBF is an excellent choice for applications that demand a stable and low-noise power supply, particularly in RF and sensitive analog circuits. Its design ensures efficient performance in a variety of settings.
