NXP USA Inc. LPC4337JET100E

Part No.:: LPC4337JET100E

Manufacturer:: NXP USA Inc.

Package:: 100-TFBGA

Datasheet:: LPC4337JET100E.pdf

Description:: IC MCU 32BIT 1MB FLASH 100TFBGA

In Stock:: 2179

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LPC4337JET100E Specifications

Package/Case:
100-TFBGA
Packaging:
Tray
Series:
LPC43xx
RoHS:
RoHS
Speed:
204MHz
RAM Size:
136K x 8
Core Size:
32-Bit Dual-Core
EEPROM Size:
16K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, IrDA, Microwire, SD, SPI, SSI, SSP, UART/USART, USB, USB OTG
Mounting Type:
Surface Mount
Number of I/O:
49
Core Processor:
ARM® Cortex®-M4/M0
Data Converters:
A/D 4x10b; D/A 1x10b
Oscillator Type:
Internal
Program Memory Size:
1MB (1M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
