NXP USA Inc. LPC2366FBD100,551

Part No.:: LPC2366FBD100,551

Manufacturer:: NXP USA Inc.

Package:: 100-LQFP

Datasheet:: LPC2366FBD100,551.pdf

Description:: IC MCU 16/32B 256KB FLSH 100LQFP

In Stock:: 2125

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LPC2366FBD100,551 Specifications

Package/Case:
100-LQFP
Packaging:
Tray
Series:
LPC2300
RoHS:
RoHS
Speed:
72MHz
RAM Size:
58K x 8
Core Size:
16/32-Bit
EEPROM Size:
-
Part Status:
Discontinued at Digi-Key
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Connectivity:
CANbus, Ethernet, I²C, Microwire, SPI, SSI, SSP, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
70
Core Processor:
ARM7®
Data Converters:
A/D 6x10b; D/A 1x10b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
