NXP USA Inc. LPC2144FBD64,151

Part No.:: LPC2144FBD64,151

Manufacturer:: NXP USA Inc.

Package:: 64-LQFP

Datasheet:: LPC2144FBD64,151.pdf

Description:: IC MCU 16/32B 128KB FLASH 64LQFP

In Stock:: 3785

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LPC2144FBD64,151 Specifications

Package/Case:
64-LQFP
Packaging:
Tray
Series:
LPC2100
RoHS:
RoHS
Speed:
60MHz
RAM Size:
16K x 8
Core Size:
16/32-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, Microwire, SPI, SSI, SSP, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
45
Core Processor:
ARM7®
Data Converters:
A/D 14x10b; D/A 1x10b
Oscillator Type:
Internal
Program Memory Size:
128KB (128K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
