Flip Electronics LPC2132FBD64/01

Part No.:: LPC2132FBD64/01

Manufacturer:: Flip Electronics

Package:: 64-LQFP

Datasheet:

Description:: RISC MICROCONTROLLER, 32-BIT, FL

In Stock:: 3669

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LPC2132FBD64/01 Specifications

Package/Case:
64-LQFP
Packaging:
Bulk
Series:
LPC2100
RoHS:
RoHS
Speed:
60MHz
RAM Size:
16K x 8
Core Size:
16/32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, Microwire, SPI, SSI, SSP, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
47
Core Processor:
ARM7®
Data Converters:
A/D 8x10b; D/A 1x10b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
