Power Integrations LNK626PG

Part No.:: LNK626PG

Manufacturer:: Power Integrations

Package:: 8-DIP (0.300, 7.62mm), 7 Leads

Datasheet:: LNK626PG.pdf

Description:: IC OFFLINE SWITCH FLYBACK 8DIP

In Stock:: 3523

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LNK626PG Specifications

Packaging:
Tube
Series:
LinkSwitch®-CV
ProductStatus:
Active
OutputIsolation:
Isolated
InternalSwitch(s):
Yes
Voltage-Breakdown:
725V
Topology:
Flyback
Voltage-StartUp:
-
Voltage-Supply(Vcc/Vdd):
-
DutyCycle:
54%
Frequency-Switching:
100kHz
Power(Watts):
17 W
FaultProtection:
Current Limiting, Open Loop, Over Temperature, Short Circuit
ControlFeatures:
-
OperatingTemperature:
-40°C ~ 150°C (TJ)
