Name: LM393DRG4
Brand: Texas Instruments
SKU: LM393DRG4
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Texas Instruments LM393DRG4

Part No.:: LM393DRG4

Manufacturer:: Texas Instruments

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: LM393DRG4.pdf

Description:: IC DUAL DIFF COMPARATOR 8-SOIC

In Stock:: 12500

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

LM393DRG4 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Discontinued at Mosen
Type:
Differential
NumberofElements:
2
OutputType:
CMOS, MOS, Open-Drain, TTL
Voltage-SupplySingle/Dual(±):
2V ~ 36V, ±1V ~ 18V
Voltage-InputOffset(Max):
5mV @ 30V
Current-InputBias(Max):
0.25µA @ 5V
Current-Output(Typ):
20mA
Current-Quiescent(Max):
2.5mA
CMRRPSRR(Typ):
-
PropagationDelay(Max):
-
Hysteresis:
-
OperatingTemperature:
0°C ~ 70°C
MountingType:
Surface Mount

LM393DRG4 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including LM393DRG4 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for LM393DRG4 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

LM393DRG4 information

Views：

LM393DRG4 Typical application Circuitry

LM393DRG4

The LM393DRG4 is a variant in the LM393 series, which is characterized by dual differential comparators. This model is designed for applications requiring precise voltage comparisons and is widely used in diverse analog processing tasks. It can operate effectively in both single and dual power supply modes.

1. Pin 1 (Output of Comparator A - LM393DRG4): In the LM393DRG4, this pin serves as the output for the first comparator. It provides the comparison result from the first comparator section.

2. Pin 2 (Inverting Input of Comparator A - LM393DRG4): This pin functions as the inverting input for the first comparator in the LM393DRG4. It is used to input the reference voltage or signal against which the non-inverting input will be compared.

3. Pin 3 (Non-Inverting Input of Comparator A - LM393DRG4): Allocated for the non-inverting input of the first comparator, this pin in the LM393DRG4 is critical for inputting the signal to be compared against the reference at the inverting input.

4. Pin 4 (Ground or Negative Power Supply - LM393DRG4): The LM393DRG4 uses this pin for grounding or connecting to the negative side of the power supply, important for the stability and reference level of the comparators.

5. Pin 5 (Non-Inverting Input of Comparator B - LM393DRG4): As the non-inverting input for the second comparator, this pin in the LM393DRG4 is used for inputting the signal to be compared in the second comparator circuit.

6. Pin 6 (Inverting Input of Comparator B - LM393DRG4): Designated as the inverting input for the second comparator, this pin in the LM393DRG4 is used to input the reference voltage or signal for the second comparator.

7. Pin 7 (Output of Comparator B - LM393DRG4): This pin provides the output from the second comparator within the LM393DRG4.

8. Pin 8 (Positive Power Supply - LM393DRG4): Essential for the operation of the LM393DRG4, this pin connects to the positive power supply.

The LM393DRG4 is commonly used in applications such as voltage level detection, window comparators, and other analog decision-making circuits. Accurate connection of each pin according to the specific needs of the circuit, while considering the IC's specifications like voltage range and output characteristics, is crucial. Understanding each pin's function in the LM393DRG4 is key to effectively utilizing this IC in electronic projects.
