STMicroelectronics L99SD01TR-E

Part No.:: L99SD01TR-E

Manufacturer:: STMicroelectronics

Package:: 36-PowerBFSOP (0.295, 7.50mm Width)

Datasheet:: L99SD01TR-E.pdf

Description:: IC SOLENOID DRIVER POWERSSO36

In Stock:: 2489

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

L99SD01TR-E Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
OutputConfiguration:
Half Bridge
Applications:
Solenoids
Interface:
I²C, PWM
LoadType:
Inductive
Technology:
Power MOSFET
RdsOn(Typ):
150mOhm LS (Max), 150mOhm HS (Max)
Current-Output/Channel:
14A
Current-PeakOutput:
-
Voltage-Supply:
6V ~ 28V
Voltage-Load:
45V (Max)
OperatingTemperature:
-40°C ~ 150°C (TJ)
Features:
Status Flag
FaultProtection:
Current Limiting, Open Load Detect, Over Temperature, Over Voltage, UVLO
MountingType:
Surface Mount
