STMicroelectronics L99H01QFTR

Part No.:: L99H01QFTR

Manufacturer:: STMicroelectronics

Package:: 32-LQFP

Datasheet:: L99H01QFTR.pdf

Description:: IC MOTOR DRIVER 6V-28V 32LQFP

In Stock:: 3652

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

L99H01QFTR Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Not For New Designs
MotorType-Stepper:
-
MotorType-ACDC:
Brushed DC
Function:
Controller - Commutation, Direction Management
OutputConfiguration:
Pre-Driver - Half Bridge (2)
Interface:
SPI
Technology:
CMOS
StepResolution:
-
Applications:
Automotive
Current-Output:
-
Voltage-Supply:
6V ~ 28V
Voltage-Load:
-
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount

L99H01QFTR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including L99H01QFTR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for L99H01QFTR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

L99H01QFTR information

Views：

L99H01QFTR Typical application Circuitry Schematics

The L99H01QFTR is a fully integrated monolithic IC for driving a single high-side N-MOSFET in automotive applications. It is developed by STMicroelectronics, and is designed to operate in applications that require high efficiency with fast switching frequencies, such as motor control, power conversion, and similar power management applications. Key characteristics and details of the L99H01QFTR include:

1. Integrated High Side Driver: The L99H01QFTR is a monolithic high side driver, specifically designed to drive a single N-channel MOSFET in applications such as relays, solenoids, and motor control.

2. Supply Voltage Range: The device operates within a supply voltage range of 6V to 28V, which makes it suitable for a broad range of automotive and industrial applications.

3. Output Current: This driver can deliver a source current of up to 1A and a sink current of up to 2A, making it suitable for driving power MOSFETs.

4. Protection Features: The L99H01QFTR is equipped with several protection features including undervoltage lockout, thermal shutdown, and load current limitation to ensure reliable and safe operation.

5. Diagnostic Functions: The IC offers various diagnostic functions such as open-load detection, overcurrent, and short-to-ground protection. Furthermore, it provides a feedback functionality that enables the microcontroller to keep track of the load's condition.

6. Compact Packaging: The L99H01QFTR is available in a compact VFQFPN package with 16 leads.

7. Applications: The device is ideal for a variety of applications, including automotive motor control, power conversion, power distribution, and other power management scenarios where high efficiency and fast switching are required.
