STMicroelectronics L6208Q

Part No.:: L6208Q

Manufacturer:: STMicroelectronics

Package:: 48-VFQFN Exposed Pad

Datasheet:: L6208Q.pdf

Description:: IC MTR DRVR BIPOLAR 8-52V 48QFN

In Stock:: 3955

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

L6208Q Specifications

Packaging:
Tray
Series:
STSPIN L62
ProductStatus:
Active
MotorType-Stepper:
Bipolar
MotorType-ACDC:
-
Function:
Driver - Fully Integrated, Control and Power Stage
OutputConfiguration:
Half Bridge (4)
Interface:
Parallel
Technology:
DMOS
StepResolution:
1, 1/2
Applications:
General Purpose
Current-Output:
2.5A
Voltage-Supply:
8V ~ 52V
Voltage-Load:
8V ~ 52V
OperatingTemperature:
-25°C ~ 125°C (TJ)
MountingType:
Surface Mount
