Microchip Technology KSZ9567STXI

Part No.:: KSZ9567STXI

Manufacturer:: Microchip Technology

Package:: 128-TQFP Exposed Pad

Datasheet:: KSZ9567STXI.pdf

Description:: IC ETHERNET SWITCH 7PORT 128TQFP

In Stock:: 3646

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

KSZ9567STXI Specifications

Package/Case:
128-TQFP Exposed Pad
Packaging:
Tray
Series:
-
ProductStatus:
Active
Protocol:
Ethernet
Function:
Switch
Interface:
I²C, SPI
Standards:
10/100/1000 Base-T PHY
Voltage-Supply:
1.8V, 2.5V, 3.3V
Current-Supply:
-
OperatingTemperature:
-40°C ~ 85°C
