Microchip Technology KSZ9563RNXI

Part No.:: KSZ9563RNXI

Manufacturer:: Microchip Technology

Package:: 64-VFQFN Exposed Pad

Datasheet:: KSZ9563RNXI.pdf

Description:: IC ETHERNET SWITCH MII 64VQFN

In Stock:: 3976

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

KSZ9563RNXI Specifications

Package/Case:
64-VFQFN Exposed Pad
Packaging:
Tray
Series:
-
ProductStatus:
Active
Protocol:
Ethernet
Function:
Switch
Interface:
MII, RMII, RGMII
Standards:
10/100/1000 Base-T PHY
Voltage-Supply:
3.135V ~ 3.465V
Current-Supply:
250mA
OperatingTemperature:
-40°C ~ 85°C
