Microchip Technology KSZ8852HLEWA

Part No.:: KSZ8852HLEWA

Manufacturer:: Microchip Technology

Package:: 64-LQFP Exposed Pad

Datasheet:: KSZ8852HLEWA.pdf

Description:: IC ETHERNET CTLR 2PORT PCI 64LQF

In Stock:: 2570

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

KSZ8852HLEWA Specifications

Package/Case:
64-LQFP Exposed Pad
Packaging:
Tray
Series:
-
ProductStatus:
Active
Protocol:
Ethernet
Function:
Switch
Interface:
Ethernet
Standards:
10/100 Base-T/TX PHY
Voltage-Supply:
3.3V
Current-Supply:
-
OperatingTemperature:
-40°C ~ 115°C
