ISSI, Integrated Silicon Solution Inc IS42S16400J-7TL

Part No.:: IS42S16400J-7TL

Manufacturer:: ISSI, Integrated Silicon Solution Inc

Package:: 54-TSOP (0.400, 10.16mm Width)

Datasheet:: IS42S16400J-7TL.pdf

Description:: IC DRAM 64MBIT PAR 54TSOP II

In Stock:: 2338

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IS42S16400J-7TL Specifications

Package/Case:
54-TSOP (0.400, 10.16mm Width)
Packaging:
Tray
Series:
-
ProductStatus:
Active
MemoryType:
Volatile
MemoryFormat:
DRAM
Technology:
SDRAM
MemorySize:
64Mb (4M x 16)
MemoryInterface:
Parallel
ClockFrequency:
143 MHz
WriteCycleTime-WordPage:
-
AccessTime:
5.4 ns
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
0°C ~ 70°C (TA)
MountingType:
Surface Mount

IS42S16400J-7TL this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including IS42S16400J-7TL price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for IS42S16400J-7TL to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

IS42S16400J-7TL information

Views：

IS42S16400J-7TL Typical application Circuitry

IS42S16400J-7TL

The IS42S16400J-7TL is a high-capacity integrated circuit from the dynamic random-access memory (DRAM) family, specifically designed for applications requiring large volumes of temporary data storage at high speeds. This device is part of the SDRAM (Synchronous DRAM) category, optimized for systems where bandwidth and data throughput are critical, such as in computing, multimedia, and high-end gaming applications.

1. Power Supply and Grounding Arrangement (VDD, VSS): For the IS42S16400J-7TL, a reliable power supply is established through the VDD pins, which need to be connected to a stable source of the nominal voltage for SDRAMs, typically 3.3V. The VSS pins serve as the ground reference for the device, ensuring a solid common ground for all signals and power within the circuit.

2. Data Bus Connectivity (DQ0-DQ15): The IS42S16400J-7TL features a 16-bit data bus, accessible through the DQ0-DQ15 pins. These pins are crucial for the bidirectional transfer of data between the SDRAM and the system's memory controller. Maintaining signal integrity and minimizing data corruption requires careful consideration of trace impedance and length matching.

3. Address and Control Signals (A0-A11, BA0-BA1, RAS, CAS, WE, CS): The address pins (A0-A11) and bank address pins (BA0-BA1) are used to specify the location within the memory array for read and write operations. To ensure effective access to the stored data, control signals known as write enable (WE), chip select (CS), column address strobe (CAS), row address strobe (RAS), and write enable (RAS) pins coordinate the time and execution of these operations.

4. Clock and Synchronization (CLK, CKE, DQM): The clock input (CLK) is essential for synchronizing the operations of the IS42S16400J-7TL with the rest of the system. The clock enable (CKE) pin allows the memory to enter a low-power state when not in use, while the data mask pins (DQM) provide control over the data bus, enabling selective read/write operations and enhancing data integrity.

5. Mode Register Set-Up (A0-A11 during MRS): The mode register set command utilizes the address pins (A0-A11) to define the operating parameters of the IS42S16400J-7TL, such as burst length, burst type, CAS latency, and operating mode. This setting is crucial for optimizing memory performance based on the application's individual requirements.

Incorporating the IS42S16400J-7TL into a memory subsystem demands meticulous planning and precision in connecting each pin, with a keen focus on signal integrity, timing accuracy, and power stability. By adhering to these guidelines, designers can harness the full potential of the IS42S16400J-7TL, achieving optimal performance in applications that demand rapid and reliable access to large volumes of data.
