Infineon Technologies IR1153SPBF

Part No.:: IR1153SPBF

Manufacturer:: Infineon Technologies

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: IR1153SPBF.pdf

Description:: IC PFC CTRLR CCM 22.2KHZ 8SOIC

In Stock:: 2278

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

IR1153SPBF Specifications

Packaging:
Tube,Tube
Series:
-
ProductStatus:
Discontinued at Mosen
Mode:
Continuous Conduction (CCM)
Frequency-Switching:
22.2kHz
Current-Startup:
26 µA
Voltage-Supply:
14V ~ 17V
OperatingTemperature:
-25°C ~ 125°C
MountingType:
Surface Mount
