Analog Devices Inc. HMC424LP3

Part No.:: HMC424LP3

Manufacturer:: Analog Devices Inc.

Package:

Datasheet:: HMC424LP3.pdf

Description:: RF ATTENUATOR 0.5-31.5DB 16VFQFN

In Stock:: 2596

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC424LP3 Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Obsolete
AttenuationValue:
0.5dB ~ 31.5dB
FrequencyRange:
0 Hz ~ 13 GHz
Power(Watts):
-
Impedance:
50 Ohms
