Analog Devices Inc. HMC346ALP3ETR

Part No.:: HMC346ALP3ETR

Manufacturer:: Analog Devices Inc.

Package:

Datasheet:: HMC346ALP3ETR.pdf

Description:: RF ATTENUATOR 30DB 50OHM 16VFQFN

In Stock:: 3289

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HMC346ALP3ETR Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
AttenuationValue:
30dB
FrequencyRange:
0 Hz ~ 14 GHz
Power(Watts):
-
Impedance:
50 Ohms
