Nexperia USA Inc. HEF4052BTT,118

Part No.:: HEF4052BTT,118

Manufacturer:: Nexperia USA Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: HEF4052BTT,118.pdf

Description:: IC MUX/DEMUX DUAL 4CH 16TSSOP

In Stock:: 1490

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HEF4052BTT,118 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
2
On-StateResistance(Max):
155Ohm
Channel-to-ChannelMatching(ΔRon):
5Ohm
Voltage-SupplySingle(V+):
3V ~ 15V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
-
-3dbBandwidth:
70MHz
ChargeInjection:
-
ChannelCapacitance(CS(off)CD(off)):
7.5pF
Current-Leakage(IS(off))(Max):
200nA
Crosstalk:
-50dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
